Name: 100 Mesh MIM Iron Metal Powder For Metal Injection Molding Cas 7439-89-6
Brand: Guangzhou Zoli Technology Co.,Ltd.
SKU: SSP-01
Availability: InStock

Home > Products > Iron Metal Powder >

100 Mesh MIM Iron Metal Powder For Metal Injection Molding Cas 7439-89-6

100 mesh MIM Iron Metal Powder

Iron Metal Powder 7439-89-6

mim metal powder 7439-89-6

Place of Origin:

China

Brand Name:

Zhongli

Certification:

ISO,CE,MSDS

Model Number:

SSP-01

Request A Quote

100 Mesh MIM Iron Metal Powder For Metal Injection Molding Cas 7439-89-6

Product Details

Solubility:

Insoluble In Water

Shelf Life:

2 Years

Applications:

Metal Injection Molding, Powder Metallurgy, Magnetic Materials, Welding Electrodes, Etc.

Cas Number:

7439-89-6

Purity:

99.9%

Storage Condition:

Store In A Cool, Dry Place

Boiling Point:

2862°C

Melting Point:

1538°C

Particle Size:

100 Mesh

Appearance:

Dark Grey Powder

Chemical Formula:

Density:

7.87 G/cm3

Molecular Weight:

55.845 G/mol

Highlight:

100 mesh MIM Iron Metal Powder

Iron Metal Powder 7439-89-6

mim metal powder 7439-89-6

Payment & Shipping Terms

Minimum Order Quantity

1kg

Packaging Details

plastic+drum

Delivery Time

within 15 days

Payment Terms

L/C,T/T,Western Union,MoneyGram

Supply Ability

15-20ton per month

Industrial 100 Micron Iron Metal Powder Anti Corrosion High Purity ODM

Get Best Price

Custom 3D Printing MIM Iron Metal Powder For Binder Jetting & SLM

Get Best Price

ODM Hydrogen Reduced Iron Metal Powder Stainless Steel Titanium Inconel

Get Best Price

Metal Fusion Atomised FE Cast Iron Powder For Precise Sintered Parts

Get Best Price

18520584493

ain@zlengineer.com

Contact Now

Product Description

100 Mesh MIM Iron Metal Powder For Metal Injection Molding (CAS 7439-89-6)

MIM Grade Iron Powder: Ideal for Metal Injection Molding Components

In advanced manufacturing, Metal Injection Molding (MIM) combines plastic injection molding versatility with metal strength and durability. MIM grade iron powder is crucial for defining final product quality and performance.

Understanding MIM Grade Iron Powder

MIM grade iron powder consists of finely atomized iron particles engineered for metal injection molding. These powders feature controlled particle size, high purity, and excellent flowability for producing complex, high-precision shapes.

Key Properties

Particle Size: 10-100 microns for optimal surface finish and dimensional accuracy
Purity: High purity with low oxygen/nitrogen content for component strength
Flowability: Spherical shape ensures easy mold flow and packing

Benefits in Metal Injection Molding

Excellent sintering properties for high density and strength
Versatile alloy composition capabilities
Consistent batch quality through strict quality control

Applications

Automotive: Gears, valve springs, steering components
Medical: Implantable joints, bone screws
Aerospace: Bearings, structural components

Material Comparison

Property	Iron-Based Alloys	Stainless Steel (316L)	Nickel Alloys	Titanium
Density (g/cm³)	7.4-7.9	7.9	8.4	4.4
Tensile Strength (MPa)	300-1,500+	500-700	900-1,200	900-1,100
Cost (vs. Pure Fe)	1x-5x	3x-5x	10x-20x	20x-30x

Powder Specifications

Particle Size	Tapping Density (g/cm³)	Particle Size Distribution (μm)
D50:12μm	>4.8	D10: 3.6-5.0 \| D50: 11.5-13.5 \| D90: 22-26
D50:11μm	>4.8	D10: 3.0-4.5 \| D50: 10.5-11.5 \| D90: 19-23

Production Equipment

Global Distribution

Frequently Asked Questions

What types of stainless steel powders are used in 3D printing?

Common grades include 316L (excellent corrosion resistance), 17-4 PH (high strength and hardness), 304L (general-purpose use), and 420 (wear resistance). Each grade has specific properties suited for different applications.

What is the typical particle size for stainless steel powders in 3D printing?

The particle size typically ranges from 15 to 45 micrometers (μm). Spherical particles are preferred for better flowability and packing density.

Can stainless steel powders be reused?

Yes, unused powder can often be recycled by sieving and blending with fresh powder. However, excessive reuse can degrade powder quality, so regular testing is recommended.

What safety precautions should be taken when handling stainless steel powders?

Avoid inhalation or skin contact by using gloves, masks, and protective clothing
Store powders in a dry, airtight container to prevent moisture absorption
Handle powders in a well-ventilated area or under inert gas to minimize explosion risks
