OEM Yttria Zirconia Alumina Ceramic Grinding Balls Beads Thermal Shock Resistant

Yttria alumina ceramic grinding balls

OEM alumina ceramic grinding balls

OEM yttria zirconia beads

Place of Origin:

China

Brand Name:

Zhongli

Certification:

CE ISO

Model Number:

ZGB-01

Request A Quote

OEM Yttria Zirconia Alumina Ceramic Grinding Balls Beads Thermal Shock Resistant

Product Details

Thermal Conductivity:

3 W/mK

Purity:

≥99.9%

Color:

White

Hardness:

HRA 90

Compatibility:

Suitable For Use In Most Grinding And Milling Machines

Chemical Resistance:

Highly Resistant To Acids And Alkalis

Size:

1mm-30mm

Shape:

Spherical

Abrasion Resistance:

≥10 Times Higher Than Glass Beads

Melting Point:

2,715°C

Application:

Grinding And Milling Of Hard And Abrasive Materials

Compressive Strength:

≥2,000 MPa

Material:

Zirconia

Density:

6.06 G/cm3

Highlight:

Yttria alumina ceramic grinding balls

OEM alumina ceramic grinding balls

OEM yttria zirconia beads

Payment & Shipping Terms

Minimum Order Quantity

1kg

Price

$20-$55/kg

Packaging Details

barrel

Delivery Time

within 15days

Payment Terms

L/C,T/T,Western Union

Supply Ability

50-200 ton/month

Advanced Tetragonal Zirconia Polycrystal Beads Optimized For Ceramic And Glass Processing

Get Best Price

Industrial Grade Zirconia Balls Designed For The Most Demanding Milling Environments

Get Best Price

Ultrafine Grinding And Dispersion Processes In Nanotechnology Applications

Get Best Price

Premium yttria-stabilized zirconia grinding media contamination-free milling

Get Best Price

18520584493

ain@zlengineer.com

Contact Now

Product Description

Product Description

Exploring the Versatility of Thermal Shock-Resistant Zirconia Balls in Extreme Temperature Milling

Name: OEM Yttria Zirconia Alumina Ceramic Grinding Balls Beads Thermal Shock Resistant
Brand: Guangzhou Zoli Technology Co.,Ltd
SKU: ZGB-01
Price: 37.00 USD
Availability: InStock

In the realm of advanced materials, thermal shock-resistant zirconia balls have emerged as a pivotal solution for milling processes under extreme temperature conditions. Known for their stability, durability, and exceptional mechanical properties, these zirconia balls are indispensable in industries demanding high precision and resilience.

Understanding Zirconia Balls: Composition and Properties

The Science Behind Zirconia Balls

Zirconia balls, primarily composed of zirconium oxide, often undergo stabilization through additives like yttria or calcia. This stabilization enhances their thermal shock resistance and mechanical strength, making them ideal for high-temperature applications. The unique crystal structure of zirconia, which can exist in monoclinic, tetragonal, and cubic forms, allows for remarkable phase transition capabilities, optimizing thermal expansion behavior and improving thermal shock resistance.

Key Properties

High Hardness and Strength: Zirconia balls boast superior hardness and strength, surpassing many other ceramic materials. This makes them ideal for applications requiring high wear resistance and mechanical durability.
Thermal Shock Resistance: Their ability to withstand rapid temperature changes without cracking is a crucial feature, especially in environments where thermal cycling is prevalent.
Chemical Stability: Resistant to corrosion and chemical attacks, zirconia balls maintain integrity even in harsh chemical environments, making them suitable for chemical industry applications.
Low Thermal Expansion: The low coefficient of thermal expansion ensures dimensional stability, crucial for precision components in high-temperature settings.

Applications of Zirconia Balls in Extreme Temperature Milling

Industrial Applications

Zirconia balls are widely used across various industries due to their robust properties:

Manufacturing Sector: In the manufacturing industry, zirconia balls are used in precision machining for components that demand high wear resistance and temperature stability, such as bearings and valves.
Chemical Industry: Their chemical resistance makes zirconia balls ideal for reactors, pump bodies, and pipelines in chemical production processes.
Aerospace Industry: The aerospace sector benefits from zirconia balls' high-temperature stability, using them in high-pressure turbines and centrifugal compressors.
Electronics Industry: Zirconia balls are integral to electronic components, offering durability and stability in energy storage devices and other electronic applications.

Advantages in Milling Processes

In milling processes, zirconia balls play a crucial role due to their:

High Efficiency: Their hardness and low wear rate enhance milling efficiency, leading to improved production rates and quality.
Precision: The consistent size and shape of zirconia balls ensure uniform milling, crucial for applications requiring high precision.
Durability: Their resistance to wear and thermal shock reduces downtime and maintenance costs, offering long-term reliability.

OEM Yttria Zirconia Alumina Ceramic Grinding Balls Beads Thermal Shock Resistant 1

Diameter(mm)	Each ball weight(g)	100g balls qty(pcs)
1	0.00314	31847
2	0.02512	3981
3	0.08478	1180
4	0.20096	498
5	0.3925	255
6	0.67824	147
7	1.07702	93
8	1.60768	62
10	3.14	32
12	5.42592	18
15	10.5975	9
20	25.12	4

●Chemical Composition:

Composition	ZrO₂	Y₂O₃+ Others
Content %	94.6	5.4

●Physical Properties:

Specific Gravity

g/cm³

Bulk Density

kg/L

Hardness

Mohs

Hardness Hv

Fracture Toughness MPam^1-2

Crushing Load

Kg.f (Φ0.3mm)

Grain size

Sphericity

(%)

≥6.03

≥ 3.76

≥1210

8.2

≤0.3

≥98

40times under microscope for 0.3mm YSZ ball

OEM Yttria Zirconia Alumina Ceramic Grinding Balls Beads Thermal Shock Resistant 3

OEM Yttria Zirconia Alumina Ceramic Grinding Balls Beads Thermal Shock Resistant 5

● Inner structure:

OEM Yttria Zirconia Alumina Ceramic Grinding Balls Beads Thermal Shock Resistant 9

● Size distribution:

product name:

Yttria stabilized zirconia bead

size:

Φ0.3mm

100pcs test result by selected random(unit: mm)

0.28

0.29

0.3

0.31

0.32

0.28

0.29

0.3

0.31

0.32

0.28

0.29

0.3

0.31

0.32

0.28

0.29

0.3

0.31

0.32

0.29

0.31

0.32

0.29

0.3

0.31

0.32

0.29

0.3

0.31

0.32

0.29

0.3

0.31

0.33

0.29

0.3

0.31

0.33

0.29

0.3

0.31

0.33

0.29

0.3

0.31

0.32

0.33

0.29

0.3

0.31

0.32

0.33

0.29

0.3

0.31

0.32

0.33

0.29

0.3

0.31

0.32

0.33

0.29

0.3

0.31

0.32

0.33

0.29

0.3

0.31

0.32

0.33

0.29

0.3

0.31

0.32

0.34

0.29

0.3

0.31

0.32

0.34

0.29

0.3

0.36

0.29

0.3

OEM Yttria Zirconia Alumina Ceramic Grinding Balls Beads Thermal Shock Resistant 11

●Features:

It has high density and hardness, making it suitable for high-quality products, such as ceramic inking, automobile, paints and coating.

It is suitable for high-efficiency horizontal mills and basket mills.

Low contamination of the milling product.

It is suitable for industries requiring nano-sized particles.

●Pakage:

25KG/Plastic Drum, 800-1000KG/Pallet with shrink wrapped

●Storage:

The grinding media should be stored in a dry and clean place.

Factory equipment

OEM Yttria Zirconia Alumina Ceramic Grinding Balls Beads Thermal Shock Resistant 12

Exhibition & Partner

OEM Yttria Zirconia Alumina Ceramic Grinding Balls Beads Thermal Shock Resistant 13

Case

Ship to philipine

OEM Yttria Zirconia Alumina Ceramic Grinding Balls Beads Thermal Shock Resistant 14

Ship to Germany

OEM Yttria Zirconia Alumina Ceramic Grinding Balls Beads Thermal Shock Resistant 16

FAQ

How do I store zirconia grinding beads?
- Store them in a dry, clean environment to prevent contamination or moisture absorption.
What is the cost of zirconia grinding beads?
- They are more expensive than other grinding media due to their superior properties, but their durability and efficiency often justify the cost.
Can zirconia beads cause contamination?
- They are highly wear-resistant, but prolonged use may cause minimal wear. Regular inspection is recommended to avoid contamination.
What industries use zirconia grinding beads?
- They are used in pharmaceuticals, paints, coatings, ceramics, electronics, and nanotechnology industries.
