Product Description
In the realm of industrial materials, achieving a flawless surface finish is crucial for enhancing the functionality and aesthetic appeal of various products. One of the most effective solutions for fine particle grinding is the use of polished precision zirconia balls. These ceramic balls are renowned for their smooth surface finish, durability, and versatility across multiple applications.
Zirconia balls, also known as zirconium oxide balls, are ceramic precision balls crafted from zirconium dioxide (ZrO2). These balls are celebrated for their high strength, toughness, and resistance to wear, corrosion, and high temperatures. Their polished precision and smooth surface finish make them ideal for fine particle grinding, ensuring impeccable results in various industrial applications.
Zirconia balls boast superior mechanical strength, making them more robust than other ceramic media. Their toughness allows them to withstand high-impact environments, ensuring longevity and consistent performance.
The polished precision of zirconia balls guarantees a smooth surface finish, which is essential for achieving fine particle grinding. This feature minimizes friction and enhances the efficiency of grinding processes.
Zirconia balls exhibit low wear rates, surpassing other grinding media like alumina and glass. Their resistance to corrosion ensures they remain intact even when exposed to harsh chemicals and extreme temperatures.
With a high density, zirconia balls provide better grinding efficiency, reducing processing times without compromising quality. This makes them an economical choice for industries seeking reliable grinding media.
Zirconia balls are ideal for precision grinding and polishing in industries such as electronics, ceramics, and chemicals. Their smooth surface finish ensures uniform particle size and enhances the quality of end products.
Due to their biocompatibility and high strength, zirconia balls are used in manufacturing medical devices and implants. Their wear resistance and chemical inertness are crucial for applications in the pharmaceutical sector.
In high-temperature and high-pressure environments like aerospace and automotive industries, zirconia balls serve as essential components in turbines, compressors, and bearings, providing stability and durability.
Zirconia balls facilitate efficient dispersion of inks and pigments, ensuring consistent color and quality in printing applications. Their precision crafting leads to superior results in the production of toners and dyes.
| Diameter(mm) |
Each ball weight(g) |
100g balls qty(pcs) |
| 1 |
0.00314 |
31847 |
| 2 |
0.02512 |
3981 |
| 3 |
0.08478 |
1180 |
| 4 |
0.20096 |
498 |
| 5 |
0.3925 |
255 |
| 6 |
0.67824 |
147 |
| 7 |
1.07702 |
93 |
| 8 |
1.60768 |
62 |
| 10 |
3.14 |
32 |
| 12 |
5.42592 |
18 |
| 15 |
10.5975 |
9 |
| 20 |
25.12 |
4 |
●Chemical Composition:
|
Composition
|
ZrO2
|
Y2O3 + Others
|
|
Content %
|
94.6
|
5.4
|
●Physical Properties:
|
Specific Gravity
g/cm3
|
Bulk Density
kg/L
|
Hardness
Mohs
|
Hardness Hv
|
Fracture Toughness MPam1-2
|
Crushing Load
Kg.f (Φ0.3mm)
|
Grain size
um
|
Sphericity
(%)
|
|
≥6.03
|
≥ 3.76
|
9
|
≥1210
|
9
|
8.2
|
≤0.3
|
≥98
|
40times under microscope for 0.3mm YSZ ball
● Inner structure:
● Size distribution:
|
product name:
|
Yttria stabilized zirconia bead
|
size:
|
Φ0.3mm
|
|
100pcs test result by selected random(unit: mm)
|
|
0.28
|
0.29
|
0.3
|
0.31
|
0.32
|
|
0.28
|
0.29
|
0.3
|
0.31
|
0.32
|
|
0.28
|
0.29
|
0.3
|
0.31
|
0.32
|
|
0.28
|
0.29
|
0.3
|
0.31
|
0.32
|
|
0.29
|
0.29
|
0.31
|
0.31
|
0.32
|
|
0.29
|
0.3
|
0.31
|
0.31
|
0.32
|
|
0.29
|
0.3
|
0.31
|
0.31
|
0.32
|
|
0.29
|
0.3
|
0.31
|
0.31
|
0.33
|
|
0.29
|
0.3
|
0.31
|
0.31
|
0.33
|
|
0.29
|
0.3
|
0.31
|
0.31
|
0.33
|
|
0.29
|
0.3
|
0.31
|
0.32
|
0.33
|
|
0.29
|
0.3
|
0.31
|
0.32
|
0.33
|
|
0.29
|
0.3
|
0.31
|
0.32
|
0.33
|
|
0.29
|
0.3
|
0.31
|
0.32
|
0.33
|
|
0.29
|
0.3
|
0.31
|
0.32
|
0.33
|
|
0.29
|
0.3
|
0.31
|
0.32
|
0.33
|
|
0.29
|
0.3
|
0.31
|
0.32
|
0.34
|
|
0.29
|
0.3
|
0.31
|
0.32
|
0.34
|
|
0.29
|
0.3
|
0.3
|
0.3
|
0.36
|
|
0.29
|
0.3
|
0.3
|
0.3
|
0.3
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
●Features:
It has high density and hardness, making it suitable for high-quality products, such as ceramic inking, automobile, paints and coating.
It is suitable for high-efficiency horizontal mills and basket mills.
Low contamination of the milling product.
It is suitable for industries requiring nano-sized particles.
●Pakage:
25KG/Plastic Drum, 800-1000KG/Pallet with shrink wrapped
●Storage:
The grinding media should be stored in a dry and clean place.
Factory equipment
Exhibition & Partner
Case
Ship to philipine
Ship to Germany
FAQ
-
How do I store zirconia grinding beads?
-
What is the cost of zirconia grinding beads?
-
Can zirconia beads cause contamination?
-
What industries use zirconia grinding beads?
-
They are used in pharmaceuticals, paints, coatings, ceramics, electronics, and nanotechnology industries.
