Name: Zirconia Planetary Mill Jar Grinding Container Used In High-energy Planetary Ball Mills
Brand: Guangzhou Zoli Technology Co.,Ltd.
SKU: BMJ-01
Availability: InStock

Home > Products > Ball Mill Jar >

Zirconia Planetary Mill Jar Grinding Container Used In High-energy Planetary Ball Mills

zirconia planetary mill jar

high-energy ball mill grinding container

planetary ball mill zirconia jar

Place of Origin:

China

Brand Name:

Zoli

Certification:

ISO CE

Model Number:

BMJ-01

Request A Quote

Zirconia Planetary Mill Jar Grinding Container Used In High-energy Planetary Ball Mills

Product Details

Weight:

40kg

Noise Level:

Less Than 50dB

Revolution Speed:

335rpm

Grinding Ball Size:

10 Mm

Certifications:

CE ISO

Programmable Control:

Yes

Grinding Balls Diameter:

10mm

Grinding Media Material:

Zirconia

Jar Surface Finish:

Polished

Jar Style:

Vertical

Color:

White

Total Height:

56mm

Control System:

Microcomputer

Jar Wall Thickness:

6 Mm

Highlight:

zirconia planetary mill jar

high-energy ball mill grinding container

planetary ball mill zirconia jar

Payment & Shipping Terms

Minimum Order Quantity

1pc

Packaging Details

carton+Pearl wool+wood

Delivery Time

within 15 days

Payment Terms

L/C,T/T,Western Union

Supply Ability

10000 per month

500ml Zirconium Oxide Ball Grinding Jar for Lab Planetary Ball Mill

Get Best Price

Zirconium Oxide Ceramic Ball Milling Tank Zirconia Planetary Ball Mill jar with Lid

Get Best Price

ZOLI Brand 1L Y-Stabilized Zirconia Milling Jar for Planetary Ball Mills

Get Best Price

50 Ml D50 X H60 Y-Stabilized Zirconia Ceramic Milling Jars For Planetary Ball Mills

Get Best Price

18520584493

ain@zlengineer.com

Contact Now

Product Description

Zirconia Planetary Mill Jar Grinding Container

A specialized grinding container used in high-energy planetary ball mills for intense grinding, mixing, homogenization, and mechanical alloying applications.

Material Composition: Yttria-Stabilized Zirconia (YSZ)

Constructed from Zirconium Dioxide (ZrO₂), a high-performance advanced ceramic stabilized with Yttria (Y₂O₃) to prevent phase transformation cracking.

Key Feature: Transformation Toughening

When stress creates micro-cracks, zirconia grains at the crack tip undergo phase change and expand, "squeezing" cracks shut for exceptional toughness and fracture resistance.

Key Properties and Advantages

Extreme Wear Resistance: Exceptional abrasion resistance for long service life
Contamination-Free Performance: Eliminates iron/chromium contamination (vs steel) and reduces alumina contamination
High Density (≥6.0 g/cm³): Delivers more impact energy for efficient size reduction
Chemical Inertness: Resistant to acids, alkalis, and organic solvents
Mechanical Strength: Withstands high-impact forces in planetary ball mills

Common Applications

Nanomaterial synthesis (metal nanoparticles, oxide ceramics)
Mechanical alloying of advanced powders
Pharmaceutical research (API size reduction)
Electronics and battery material development
Geology/archaeology sample preparation
High-purity ceramics processing

Material Comparison

Property	Zirconia (YSZ)	Alumina	Stainless Steel	Polyurethane
Primary Advantage	Best Toughness & Low Contamination	Good Wear Resistance & Cost	High Impact Strength	Low Cost & Noise
Hardness	Very High	Highest	Low	Very Low
Contamination	Zr, Y	Al	Fe, Cr, Mo	Organic

Selection and Usage Guidelines

Fill jar to 1/3-1/2 capacity for optimal efficiency
Use zirconia grinding balls for contamination-free milling
Ensure proper sealing mechanism (O-ring) to prevent sample loss
Clean with dilute acid, distilled water, and ethanol after use
Inspect for chipping or wear before each use

Note: While offering superior performance, zirconia jars have higher cost and weight compared to alternatives, and may introduce trace ZrO₂/Y₂O₃ in contamination-sensitive applications.

Zirconia Planetary Mill Jars represent the gold standard for contamination-sensitive processes in nanomaterials, advanced batteries, and pharmaceuticals where product purity is critical.
