Name: ZTA Composite Zirconia Toughened Alumina Grinding Balls Pebbles Impact Resistance
Brand: Guangzhou Zoli Technology Co.,Ltd.
SKU: AGB-01
Availability: InStock

Home > Products > Alumina Grinding Balls >

ZTA Composite Zirconia Toughened Alumina Grinding Balls Pebbles Impact Resistance

ZTA Composite Alumina Grinding Balls

Zirconia Toughened Alumina Grinding Balls

Zirconia alumina pebbles

Place of Origin:

China

Brand Name:

Zhongli

Certification:

CE ISO

Model Number:

AGB-01

Request A Quote

ZTA Composite Zirconia Toughened Alumina Grinding Balls Pebbles Impact Resistance

Product Details

Hardness:

9 Mohs

Packing Density:

3.6-3.8 G/cm3

Water Absorption:

≤0.01%

Thermal Expansion Coefficient:

5x10^-6/℃

Size:

1mm-50mm

Shape:

Spherical

Material:

Alumina

Chemical Resistance:

Excellent

Crushing Strength:

≥2000N

Density:

3.6-3.9 G/cm3

Thermal Conductivity:

Low

Abrasion Resistance:

Excellent

Usage:

Grinding And Milling Applications

Color:

White

Highlight:

ZTA Composite Alumina Grinding Balls

Zirconia Toughened Alumina Grinding Balls

Zirconia alumina pebbles

Payment & Shipping Terms

Minimum Order Quantity

1kg

Packaging Details

plastic + barrel

Delivery Time

within 15 days

Payment Terms

L/C,T/T,Western Union

Supply Ability

40-200ton per month

92% 95% 99% Ceramic Alumina Balls Grinding Mill Media Custom

Get Best Price

Al₂O₃ Ceramic Alumina Grinding Balls Zero Contamination for Pharma & Food

Get Best Price

Sintered Milling Ceramic Alumina Grinding Balls Media 1000kg/Pallet

Get Best Price

White Ceramic Alumina Grinding Balls Diamonds Ultra Hard Milling Media

Get Best Price

18520584493

ain@zlengineer.com

Contact Now

Product Description

ZTA Composite Zirconia Toughened Alumina Grinding Balls Pebbles Impact Resistance

Advanced Material for Superior Impact Resistance

Zirconia-Toughened Alumina (ZTA) composite balls represent a breakthrough in grinding media technology, combining alumina's hardness with zirconia's fracture toughness for exceptional impact resistance and wear performance.

Key Properties of ZTA Composite Balls

Increased Fracture Toughness: Superior resistance to impact loading compared to standard alumina materials
Excellent Wear Resistance: Smooth microstructure provides 2-15 times better wear resistance than high alumina media
Thermal Stability: Efficient heat dissipation for high-temperature applications
Chemical Inertness: Resistant to acids, alkalis, and corrosive environments

Chemical Composition

Composition	Al2O3	SIO2	CaO+MgO	Fe2O3
Wt%	≥92	7 max	≤2	＜0.1

Physical Properties

Property	Value
Specific Gravity (g/cm3)	≥3.65
Bulk Density (kg/L)	≥2.2
Hardness (Moh's)	9
Water Absorption (%)	＜0.01
Self Wearing Loss % (24hrs)	≤0.012
Compression (Mpa)	≥2000

Available Sizes (mm)

0.5-1.0	6.0	20.0	70.0
1.0	8.0	25.0	80.0
2.0	10.0	30.0	90.0
3.0	13.0	40.0	100.0
4.0	15.0	50.0
5.0	18.0	60.0

Performance Comparison

Property	Alumina (92%)	Alumina (99%)	Zirconia	Steel	Silica Sand
Density (g/cm³)	3.6	3.9	6.0	7.8	2.2
Hardness (Mohs/HV)	9 (~1,500 HV)	9 (~1,800 HV)	8.5	6-7	7
Wear Rate (g/ton)	10-50	5-20	1-5	100+	300+
Compressive Strength	2,000 MPa	2,500 MPa	2,200 MPa	500 MPa	Low

Key Advantages

30% lower wear than standard 92% alumina grade
2-5x longer lifespan compared to steel in abrasive applications
Superior hardness to zirconia for fine grinding applications
Cost-effective alternative to pure zirconia media

Industrial Applications

Mining & Mineral Processing: Improved grinding efficiency with reduced contamination
Pharmaceuticals: FDA-compliant, no endotoxin release
Battery Manufacturing: Prevents metal contamination in cathode materials
Paints & Coatings: Maintains color purity with no metal leaching
Medical & Aerospace: Biocompatible and thermally stable for demanding applications

Packaging Information

Standard packaging includes 25KG woven bags, with 1000KG-1250KG per pallet shrink wrapped for secure transportation.

Frequently Asked Questions

What are ZTA composite balls made of?

They are composed of aluminium oxide (Al₂O₃) reinforced with zirconia (ZrO₂), creating a high-performance ceramic material with enhanced toughness.

What are the key advantages of ZTA balls?

ZTA balls offer superior impact resistance, excellent wear properties, chemical stability, and thermal resistance up to 1600°C.

Why choose ZTA over other grinding media?

ZTA provides the optimal balance between cost and performance, offering zirconia-like toughness at a more economical price point.

What customization options are available?

We offer various sizes (1mm-100mm), zirconia content adjustments, and specialized grades to meet specific application requirements.
