Planetary Ball Mill Machine for Laboratory Use
The Planetary Ball Mill Machine is a highly efficient laboratory instrument designed for mixing, fine grinding, and mechanical alloying applications. Engineered to deliver precise particle size reduction, this equipment is ideal for research and industrial settings requiring uniform sample preparation and material processing.
Nano Powder Grinding Capability
This ball mill excels as a nano powder grinding machine, utilizing planetary motion to generate high-energy impacts and friction. The result is ultra-fine powders down to 1μm, essential for advanced research in material science and nanotechnology.
Flexible Configuration Options
Available with grinding jars in 50ml, 100ml, and 250ml volumes to accommodate various sample quantities. The machine supports grinding balls in both 3mm and 10mm diameters, allowing optimization for different materials and grinding requirements.
Robust Performance
Powered by a 380W motor that ensures stable high-speed operation, this ball grinding mill delivers consistent performance for mechanical alloying and thorough mixing with minimal noise and vibration.
Key Features
- Planetary Ball Mill Machine for laboratory applications
- Achieves final fineness of 1μm for ultra-fine grinding
- Compatible with 10mm grinding balls for ball mill operations
- 380W motor power for efficient operation
- Durable stainless steel construction
- High-performance lab ball milling machine for R&D
- Efficient ball grinding mill for fine powder production
Technical Specifications
| Parameter |
Specification |
| Jar Volume |
50ml / 100ml / 250ml |
| Dimensions |
500mm × 300mm × 340mm |
| Control Type |
Digital Display with Timer |
| Timer Range |
1 second - 99 hours 59 minutes |
| Final Fineness |
1μm |
| Voltage |
220V / 50Hz |
| Applications |
Mixing, Fine Grinding, Mechanical Alloying |
| Speed Ratio |
1:2 |
| Motor Power |
380W |
| Grinding Ball Diameter |
3mm |
Applications & Certification
The Zhongli Planetary Ball Mill Machine (model ZLXQM) is ISO 9001 and CE certified, ensuring quality and safety standards. Weighing 30kg with compact dimensions, it's ideal for university laboratories, research centers, and industrial R&D facilities.
This ball mill processes various materials including metals, ceramics, and chemicals, supporting material synthesis, sample preparation, and mechanical alloying applications. Minimum order quantity is 1 unit with a supply capacity of 200 units monthly.
Delivery & Payment: Standard delivery within 15 days. Packaging includes carton and wood for secure transport. Payment terms: L/C, T/T, and Western Union accepted.
