Laboratory desktop planetary ball mill 0.4L small nano-scale high-energy ball mill

0.4L laboratory planetary ball mill

small nano-scale ball mill

high-energy desktop ball mill

Place of Origin:

China

Brand Name:

Zoli

Certification:

ISO 9001 CE

Model Number:

XQM

Request A Quote

Laboratory desktop planetary ball mill 0.4L small nano-scale high-energy ball mill

Product Details

Final Fineness:

1μm

Model:

XQM-0.4L

Min Speed:

50 Rpm

Grinding Jar Type:

4 Jars

Material Compatibility:

Ceramics, Chemicals, Minerals, Metals

Timer Range:

0-99 Minutes

Weight:

40kg

Rotation Speed Ratio:

2/3

Capacity:

Warranty:

1 Year

Grinding Balls Material:

Zirconia, Agate, Alumina, Nylon, PTFE

Discharging Granularity:

0.1 Micron Minimum

Feeding Granularity:

<=1mm

Net Weight:

40 Kg

Frequency:

50/60Hz

Highlight:

0.4L laboratory planetary ball mill

small nano-scale ball mill

high-energy desktop ball mill

Payment & Shipping Terms

Minimum Order Quantity

1 set

Packaging Details

carton+wood

Delivery Time

within 15days

Payment Terms

L/C,T/T,Western Union

Supply Ability

200 units per month

powerful, precise, and space-efficient solution planetary ball mill with vacuum jars

Get Best Price

Specialized Geochemical Sample Preparation System Small Vertical Laboratory Grinding Machine

Get Best Price

Cost-effective And Application Specific Solution Of ZOLI Planetary Ball Mills

Get Best Price

Vertical planetary ball mill, laboratory-specific nano planetary mill, small intelligent planetary ball mill

Get Best Price

18520584493

ain@zlengineer.com

Contact Now

Product Description

Laboratory Desktop Planetary Ball Mill 0.4L Small Nano-Scale High-Energy Ball Mill

Detailed Feature Breakdown

0.4L Capacity

The 0.4L (400 ml) capacity refers to the total combined volume of all grinding jars when fully loaded. Typically configured with four 100ml jars or two 200ml jars, this capacity is ideal for small to medium-sized research labs, enabling multiple sample processing under identical conditions for experimental consistency and lab efficiency.

High-Energy Ball Mill

The high-energy performance comes from planetary motion with rotational speeds ranging from 800 to 1500 RPM, generating immense centrifugal forces for powerful grinding ball impacts. This enables nano-scale grinding of hard, brittle, or tough materials with faster processing times compared to standard ball mills.

Nano-Scale Capability

Designed to reduce particles to 1-100 nanometers, this requires:

High-energy impact forces
Small, hard grinding balls (0.1-3mm Zirconia)
Precise digital control of time and speed
Contamination-resistant jar materials like Yttria-stabilized Zirconia or Agate

Laboratory Desktop Design

Compact benchtop instrument with small footprint for easy lab installation. Designed for R&D and small-batch processing, handling sample sizes from a few grams to 50-100 grams per jar depending on material density.

Typical Specifications

Type	Planetary Ball Mill
Total Capacity	0.4 Liters (e.g., 4 x 100ml jars)
Speed Range	Programmable, up to 1000 RPM or higher
Control	Digital display for speed and time with cycle programming
Power	High-power motor for full-load operation
Jar Materials	Stainless Steel, Nylon, Agate, Zirconia

Ideal Applications

Materials Science: Nano-powder synthesis for composites, catalysts, and advanced ceramics
Pharmaceutical Development: Nano-milling of APIs to enhance solubility and bioavailability
Geology/Mining: Preparation of fine, homogeneous powders for chemical analysis (XRF, ICP)
Mechanical Alloying: Creating novel nano-structural alloys from elemental powders
Chemistry: Mechanochemical reactions
